Double sided microboard for IBM PC & XT

Double sided microboard for IBM PC & XT
RS Stock No. 435-686
Brand Vero Technologies
Mfr Part No. 22-42697
RoHS Status Compliant
IBM® PC and XT Compatible

This has power rails for +5 V, -5V, +12 V, -12 V, in addition to 0 V.There are also 5 uncommitted distribution strips which may be connected to a voltage or signal line if required.

Kindly donated by Julian Bryant

Date : 1987

Manufacturer : RS

This exhibit has a reference ID of CH30358. Please quote this reference ID in any communication with the Centre for Computing History.


Scan of Document: Double sided microboard for IBM PC & XT

Click on the Image For Detail
