Cray-1

GLD PLOT

Cray-1 GLD PLOT Calcomp Compatible Plotting Package

for Cray-1 and Data General Eclipse using Gould 5000 Plotter

Version 1A

September 1981

Alistair Mills

This manual is user documentation for a subroutine package which allows the user to use the Gould printer/plotter on the Data General Eclipse maintenance control unit, as a plotter. The package runs on the Cray-1 and disposes plotter files directly. The only processing which is carried out on the Data General is that required to read the disk file in raster mode onto the plotter. A simple CLI command performs this operation.

The package has been designed to be upwards compatible on Calcomp basic software. Calcomp basic software has ten possible calls. This package has 21 calls of which 10 are similar to Calcomp, 3 are utilities which enable the user to control output appearance, 5 are utilities which are used internally and may be useful to the user, 2 are utilities which are use internally, and should not be used by the user, and 1 is for debugging.


Reference Number :

Date Published : September 1981

Manufacturer : Cray Research Inc

Platform : GLD Plot

Format : PDF - 63 Pages











This exhibit has a reference ID of CH2264. Please quote this reference ID in any communication with the Centre for Computing History.


Cray-1 GLD PLOT Calcomp Compatible Plotting Package

Click on the Images For Detail

This manual can be downloaded from the Computing History Shop.

  • File Size: 2.44 MB
  • Price: £1.00
