SA400L Minifloppy Diskette Storage Drive - Service Manual

This manual provides depot level maintenance information necessary to maintain, trouble-shoot, and repair the
SA400L Minifloppy disk drive manufactured by Shugart. Aseparate OEMmanual (SA400LOEMP/N 39019) is
available which describes the installation, interface, and power requirements useful for the applications of the
SA400L.


The SA400L floppy drives have these standard features:
a. Compact size and weight similar to most tape cassette units.
b. Single and double density capability.
c. 125/250 k bytes (unformatted) storage capacity.
d. 125/250 k bits/second transfer rate.
e. Low heat dissipation.
f. Positive media insertion to avoid media damage.
g. DC drive motor (eliminates ac requirements).
h. Proprietary read/write head designed and manufactured by Shugart.
i. Write protect circuitry,
j. Activity light.

Includes circuit diagrams


Reference Number : 39028-1

Date Published : Unknown

Manufacturer : Shugart

Platform : SA400L

Format : PDF











This exhibit has a reference ID of CH40079. Please quote this reference ID in any communication with the Centre for Computing History.


SA400L Minifloppy Diskette Storage Drive - Service Manual

Click on the Images For Detail

This manual can be downloaded from the Computing History Shop.

  • File Size: 3.32 MB
  • Price: £4






Help support the museum by buying from the museum shop
