ICT Punched Tape tool No: 588254

One of the first methods of storing data and software for use on a computer was the use of punched paper tape. The tape was fed through a special tape reader and the rows of dots converted to numbers. Each dot corresponds to a BInary digiT (or BIT) of data. Eight bits in a group are called a BYTE (some people refer to half a byte, or 4 bits, as a NYBBLE).

The stainless steel ICT E.S.O. Tool No. 588254 is used to check that the punched tape (5, 7 or 8 channel) is accurate to ensure that the the tape can be read correctly. A punched  secion of the tape is laid over the template to check the alignment.

1 The guide edge of the tape is palced against the pins to check that the location hole is within tolerence along the limit line 'A'
2 The relative position of code holes on 'B' are also to be checked
3 To check pitch place tape along 'C'
4 Check width of tape at 'F'

Date : 1966

Manufacturer : ICT

This exhibit has a reference ID of CH6009. Please quote this reference ID in any communication with the Centre for Computing History.


Scan of Document: ICT Punched Tape tool No: 588254
